KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift

KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift
KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift
Βασικές πληροφορίες
Τόπος καταγωγής: Jiangsu, Κίνα
Μάρκα: KAD
Ποσότητα παραγγελίας min: 1
Τιμή: $1,285-1,680
Καλύτερη τιμή Επικοινωνήστε
Διχαλωτό μήκος: 1070 mm Πλάτος δικράνων: 550/680 χιλιοστά
Κέντρο φόρτωσης: 500mm Βάρος φορτίου: 1500 κιλά
Τάση μπαταρίας: 24V Χωρητικότητα μπαταρίας: 80Ah
Τύπος μπαταρίας: Μολύβι οξέος Min Υψόμετρο ανύψωσης: 2080mm
Συνολικές διαστάσεις: 1770x850x2080mm Βάρος: 500 κιλά
οδηγώντας ταχύτητα: 5,0 χιλ./δευτ. Ταχύτητα ανύψωσης: 140/135 χιλ./δευτ.
Μειωμένη ταχύτητα: 150/155mm/s Κινητήρας οδήγησης: Συνεχής ρεύμα/0,75 kW
Ανυψωτικός κινητήρας: Συνεχής ρεύμα/2,2 kW
Επισημαίνω:

1600kg electric pallet stacker

,

3000mm lift pallet stacker

,

KAD electric pallet stacker

KAD CDDW1630 1600kg 3000mm Electric Pedestrian Stacker Hydraulic Walkie Forklift
Product Specifications
Attribute Value
Condition New
Fork Length 1070mm/customized
Fork Width 550/680mm/customized
Applicable Industries Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works, Energy & Mining, Food & Beverage Shops, Advertising
Terrain Adaptability Indoor Flooring, Outdoor Pavement, other
Load Center 500 mm
Load weight 1500KG
Battery 24V/80Ah
Battery type Lead acid battery
Power Source DC MOTOR
Warranty 1 Year
Min. Lifting Height 2080mm
Overall Dimensions 1770(L)*850(w)*2080(h)
Weight (KG) 500 kg
Product Description
The KAD CDDW1630 electric pedestrian stacker is designed for small warehouses, production facilities, and retail environments. Its compact dimensions make it ideal for operation in limited spaces, optimizing daily working routines while saving labor.
KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift 0 KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift 1 KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift 2 KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift 3
Key Features
  • Curtis controller - Serviceable by any forklift service company worldwide
  • Integrated charger - Provides flexibility for modern supply chain needs
  • Maintenance-free batteries - No water addition required
  • High strength forks - Durable construction for heavy loads
  • Night operation lights - Ideal for warehouses with insufficient lighting
  • Safety features - Includes reverse rearview mirror and buzzing sound
  • Durable mast - 3-stage design supports heavy loads at 4-4.5m
Technical Specifications
Model CDDW10 CDDW15
Drive system Battery
Driving mode Walkie
Load Capacity (KG) 1000 1500
Load Center (MM) 500
Lifting Height (MM) 1600/2000 2500/3000
Driving Speed (Empty/Full Load) (MM/S) 5.0/5.0
Lifting Speed (Empty/Full Load) (MM/S) 140/135
Battery Capacity (V/Ah) 24/80Ah
Main Components

Control Handle: Domestic famous control handle with functional buttons for UP/DOWN, FORWARD/BACKWARD control. Features Curtis brand accelerator for safe operation.

KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift 4 KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift 5 KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift 6
Our Services
KAD CDDW1630 Electric Pallet Stacker 1600kg Load 3000mm Lift 7
Pre-Sales Service
  • Inquiry and consulting support
  • Sample testing support
  • Factory viewing available
After-Sales Service
  • Machine installation and operation training
  • Overseas engineer support for distributors
Frequently Asked Questions
Q1. What is your terms of packing?
A: Generally, we pack our goods in paper package and Iron pallet. We can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. Or as negotiated.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 5 to 30 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
